GY-PGLPC 100W
| Input Voltage | 120-277V |
| Input Freq | 50/60Hz |
| Input Power | 100W |
| Power Factor | 0.9 min |
| THD | 20% max |
| PPF |
240.00 μmol/s |
| PPE |
2.40 μmol/J |
| Thermal Management | Passive |
| Operating Temp | -20℃ to 40℃ |
| Ingress Protection | Dry and damp location |
| Q70 Life | 50,000 hours |
| Warranty | 5 year |
| Tent | 4x4ft to 5x5ft |
|
Length (L) |
6.85” (1190mm) |
|
Width (W) |
16.14” (410mm) |
|
Height (H) |
1.0” (25mm) |
GY-PGLPC 180W
| Input Voltage | 120-277V |
| Input Freq | 50/60Hz |
| Input Power | 180W |
| Power Factor | 0.9 min |
| THD | 20% max |
| PPF |
450.00 μmol/s |
| PPE |
2.50 μmol/J |
| Thermal Management | Passive |
| Operating Temp | -20℃ to 40℃ |
| Ingress Protection | Dry and damp location |
| Q70 Life | 50,000 hours |
| Warranty | 5 year |
| Tent | 4x4ft to 5x5ft |
|
Length (L) |
42.8” (1087mm) |
|
Width (W) |
17.09 ” (521 mm) |
|
Height (H) |
1.25” (38mm) |
GY-PGLPC 320W
| Input Voltage | 120-277V |
| Input Freq | 50/60Hz |
| Input Power | 320W |
| Power Factor | 0.9 min |
| THD | 20% max |
| PPF |
769.39 μmol/s |
| PPE |
2.41 μmol/J |
| Thermal Management | Passive |
| Operating Temp | -20℃ to 40℃ |
| Ingress Protection | Dry and damp location |
| Q70 Life | 50,000 hours |
| Warranty | 5 year |
| Tent | 4x4ft to 5x5ft |
|
Length (L) |
47” (1194mm) |
|
Width (W) |
42.8” (1087mm) |
|
Height (H) |
1.97” (50mm) |
GY-PGLPC 630W
| Input Voltage | 120-277V |
| Input Freq | 50/60Hz |
| Input Power | 630W |
| Power Factor | 0.9 min |
| THD | 20% max |
| PPF |
1700.00 μmol/s
1900.00 μmol/s |
| PPE |
2.7 μmol/J |
| Thermal Management | Passive |
| Operating Temp | -20℃ to 40℃ |
| Ingress Protection | Dry and damp location |
| Q70 Life | 50,000 hours |
| Warranty | 5 year |
| Tent | 4x4ft to 5x5ft |
|
Length (L) |
47” (1194mm) |
|
Width (W) |
42.8” (1087mm) |
|
Height (H) |
1.97” (50mm) |
