Cold cathode lamp

Cold cathode lamp

  1. Ideal for germicidal system, water and air treatment.
  2. Various of holders for chioce
  3. Quartz glass material, the tube is strong enough.
  4. Average lifetime 8000 hours
  5. Ozone-free, ozone-generating, high-output, instant and amalgam lamp are available
  6. Quartz sleeve and electrical ballast can be served
Cold cathode lamp series
Wave length 253.7nm
voltage Customized
Power Customized
Pin 1pin, 2pin, 4pin
installation freestanding
Lifetime 13000 hours
Diameter 4mm 5mm 7mm
Main body Material Quartz glass
End material Ceramic, aluminum, plastic
Warranty 1 year

Product Description





No exposed to the light directly!!!
Customization is available !
Ozone-free, ozone-generating, high-output, instant and amalgam lamp are available

Lamp Description Diameter(mm) Length(mm) Power(w) Voltage(v) Current(mA) Peak wave length(nm) Intensity(1m)(μW/cm2) Lifetime(h)
ZLU4-35W 4 35 0.9 160 5.7 253.7 1300 12000
ZLU4-40W 4 40 1.1 180 5.6 253.7 1300 12000
ZLU4-55W 4 55 1.3 240 5.4 253.7 1300 12000
ZLU4-60W 4 60 1.3 240 5.3 253.7 1300 12000
ZLU4-70W 4 70 1.3 280 5.4 253.7 1300 12000
ZLU5-53W 5 53 1.2 228 5.3 253.7 14000 13000
ZLU5-60W 5 60 1.3 250 5.3 253.7 14000 13000
ZLU5-100W(DU) 5 100 1.8 275 6.5 253.7 6000 13000
ZLU5-150W 5 150 2.5 450 5.8 253.7 10000 13000
ZLU5-250W 5 250 5.8 650 9.7 253.7 15000( 13000
